Description
BEP M28-DCSM Millennium Circuit Breaker Panel with vertical 28-position layout and digital meter, suitable for 12V DC systems.
Single pole circuit breakers: 8x 5A, 8x 10A, 8x 15A, 2x 20A and 2x 30A.
Maximum Amperage: 160A per bus
Height: 370mm (14.6″)
Width: 239mm (9.75″)
Depth: 65mm (2.5″)
Neg Bus: 24-way
12V DC
Compact sizing
Battery monitoring using BEP multifunction meter (voltage on 3 battery banks, charge, discharge amps and amp-hours remaining on main battery bank)
Label sets (1-4) and busbar supplied with panels
Depth for mounting 2.5″ (64 mm) all panels
SKU: 891131
