Description
BEP M32-DCSM Millennium Circuit Breaker Panel with horizontal 32-position layout and digital meter, suitable for 12V DC systems.
Single pole circuit breakers: 7x 5A, 11x 10A, 11x 15A, 1x 20A, 1x 25A and 1x 30A.
Maximum Amperage: 160A per bus
Height: 285mm (11.25″)
Width: 351mm (13.9″)
Depth: 65mm (2.5″)
Neg Bus: 24-way
12V DC
Compact sizing
Battery monitoring using BEP multifunction meter (voltage on 3 battery banks, charge, discharge amps and amp-hours remaining on main battery bank)
Label sets (1-4) and busbar supplied with panels
Depth for mounting 2.5″ (64 mm) all panels
SKU: 891132
