Description
BEP NC36NM Circuit Breaker Panel with square 36-position layout, suitable for 12V DC systems.
Single pole circuit breakers: 5x 5A, 8x 10A, 8x 15A, 1x 20A, 1x 25A and 1x 30A.
Maximum Amperage: 160A per bus
Height: 285mm (11.25″)
Width: 351mm (13.9″)
Depth: 65mm (2.5″)
Neg Bus: 24-way
Red LED indicates systems on
12V DC
Marine grade powder coated aluminium
ABYC standard voltage indication
Green LED backlit labels
Stylish clip-on contour fascia
Label sets (1-4 & 6) and busbar supplied with panels
Cut-out size – 10mm (3/8″) inside all external edges
Depth for mounting 2.5″ (64 mm) all panels
SKU: 891030
