Description
CZone MasterBus Bridge Interface 80-911-0072-00 physically connects the MasterBus and CZone networks together, enabling the two networks to communicate and act as one. This provides seamless control and monitoring of devices from either MasterBus displays, CZone displays or integrated products.
Features/functions:
– Control of Mastervolt inverters and chargers from CZone displays, switches or integrated products.
– Control of CZone output devices (turn lights, pumps, etc. on/off) via MasterBus displays and switches.
– Display CZone acquired systems information such as tank and power levels on MasterBus displays.
– Display MasterBus acquired systems information such as tank and power levels on CZone displays.
– Transfer of alarms between both systems.
General specifications
MasterBus powering: no
Dimensions: Height 69mm x Width 69mm x Depth 50mm (2.7″ x 2.7″ x 2.0″)
Weight: 0.145 kg (0.3 lb)
Delivered with: MasterBus cable adapter, MasterBus terminator, manual
Technical specifications
Current consumption: 60 mA, 720 mW
DIN rail mounting: no
Protection degree: IP65
SKU: 894258
