Description
Marinco 2.5 waterproof wiper motor 12V with 2 speeds, 2-1/2″ shaft and 80 degree sweep. The windscreen wiper motor features a fully sealed powder coated aluminium waterproof base and housing.
Powers a 26″ (660mm) Deluxe arm and Deluxe blade combination or a 24″ (609mm) Premier arm and Premier blade combination
Shaft length: 2.5″ (68mm), *includes 0.5″ (13mm) length of knurled arm fitting
Factory pre-set sweep angles of 80ø, with easy adjustment to 45ø or 60ø
Chrome plated solid brass knurled drive nut with brass and stainless steel drive shaft
Two speed motor
Sealed 6″ wire leads, 16 AWG
Adjustable right or left self parking
0.625″ (16mm) diameter shaft
Coast to park
RF shielded circuitry
Includes 6 amp fuse and holder (operating switch not included)
Measures approximately (L x W x D): 7.875″ (200mm) x 4.25″ (108mm) x 3″ (76mm) – see drawing
Stall torque: 139 in-lbs (160 kgf/cm; 15.7 Nm)
Stall current: 9.0 – 10.5 amps
No load current: 1.0 -1.6 amps
SKU: 611264
