Description
Easily convert Transducer signals to SeaTalkNG.
The Raymarine iTC-5 converts analogue transducer signals used in i70 ST70+ and ST70 instrument systems to SeaTalkNG. Transducers for Speed/Temperature Depth Wind Rudder Angle and Fluxgate Compass can be connected to the one iTC-5 unit eliminating the need for multiple ST70 pods. Extended STng systems can support multiple iTC-5 units. SeaTalkNG connections at the base of the unit simply connect the iTC-5 unit into the SeaTalkNG backbone.
Please note the ST40/i40/i50/i60 and ST60+ displays cannot calibrate the iTC-5. Only the i70 has full transducer calibration. The ST70/ST70+ can calibrate the Depth Wind and Speed/Temp transducers (not Rudder or Compass). If you don’t have an ST70/ST70+ or i70 in your system then the ST40/i40/i50/i60/ST60+ displays must be interfaced directly to the relevant analogue transducers.
Compatible & Related Products
Useful compatible products and accessories recommended for this item.
Raymarine
Raymarine SeaTalk NG (STNG) Power Cable
SeaTalk ng Power cable - A cable to connect a SeaTalk ng backbone to a 12V switched power supply. This provides power to the whole network and attached devices. Only one power cable is used per network. When attached at the mid-point of a network, this cable powers each half of the network independently. SeaTalk ng is a robust cabling and connection system compatible with NMEA 2000, built specifically for the marine environment comprising a powered single backbone with two terminators, one at each end. Small diameter cable connectors are used throughout the system to make installation easier. There’s a wide range of cable lengths, all with over-moulded plugs, so there is no need to cut or splice cables. Spur cables connect individual SeaTalk ng products to the SeaTalk ng backbone. Cables and connectors are colour-coded for easy system identification and have quick connect (push-fit, twist-lock) waterproof (IPx6) plugs and sockets. Whether you are looking to expand your current SeaTalk ng system, update your electronics suite or completely refit, it couldn’t be easier with SeaTalk ng.
Raymarine
Upgrade Options
Alternative or higher-specification products you may also wish to consider.
Raymarine
Raymarine SeaTalk NG (STNG) Backbone Kit
SeaTalkNG is a robust cabling and connection system compatible with NMEA 2000, built specifically for the marine environment comprising a powered single backbone with two terminators, one at each end. Small diameter cable connectors are used throughout the system to make installation easier. There’s a wide range of cable lengths, all with over-moulded plugs, so there is no need to cut or splice cables.
Raymarine
Raymarine SeaTalk (ST1) to SeaTalk NG (STNG) Adaptor Kit
SEATALK 1 to SeaTalkNG Converter Kit The SEATALK 1 to SeaTalkNG converter allows select SeaTalk 1 devices to interface and communicate on the Raymarine SeaTalkNG data network. It is compatible with legacy ST40, ST60+, Raystar 125 GPS sensors and LifeTag Wireless Man Overboard Systems. The SeaTalk to SeaTalkNG Converter kit is a compact solution that connects in-line with the SeaTalkNG instrument network. The converter kit includes all of the necessary components to interface to SeaTalk 1 devices, and establish basic SeaTalkNG connectivity on the vessel including: SeaTalk 1 to SeaTalkNG converter SeaTalkNG Terminators (x2) SeaTalkNG Blanking Plugs (x2) 400mm (15-inch) SeaTalk 1 to SeaTalkNG converter cable SeaTalkNG power cable, 1m (3.3-foot) SeaTalkNG spur cable.
Raymarine
Raymarine
Raymarine SeaTalk (ST1) to SeaTalk NG (STNG) Convertor only
Raymarine’s proprietary network design released at the same time as NMEA0183 that had several key advantages. SeaTalk1 is included in many Raymarine MFDs and instruments to provide legacy support but now NMEA 2000 offers several advantages over SeaTalk1.
