Description
The Vetus Ultrasonic level sender, Vetus SENSORA provides contactless measuring of the tank contents. The Vetus SENSORA is suitable for use with petrol, diesel, drinking water, grey waste water and black waste water.
The Vetus SENSORA level sensor can be easily calibrated with the aid of an LED and calibration wire: no other equipment is required. Vetus ultrasonic level sensor may be installed in most non-metallic tanks with a maximum tank depth of 120cm. When fitting the Vetus SENSORA to a Vetus fuel tank filler kit FTKIT, then adaptor V-SENSORR must also be ordered. The sensor may be connected to all standard Vetus analogue level indicators and also to the Vetus waste water control panel (WWCP).
Technical details of the Vetus V-SENSORA Ultrasonic level sensor
– Voltage: 12 and 24 volts DC
– Current consumption: 35 mA
– Interface: Analogue
– Tank depth: 120 cm (max)
– Accuracy: +/- 5%
– Temperature range: -20øc to +70øC
– Flange: SAE, 5 hole
– Dimensions: 77mm diameter x 23mm deep
SKU: VSENSORA
