Description
The Victron GX Tank 140 takes readings from up to 4 tank level sensors. It is an accessory for the Victron Cerbo GX system monitors. Tank levels can be read-out locally in the system, as well remotely through Victron’s VRM Portal.
The GX Tank is compatible with 4mA to 20mA current senders as well as 0V to 10V voltage senders. The Victron BPP920140100 connects to the Cerbo GX Device via USB, which is also how the GX Tank gets its power – no additional power wires required.
For marine applications, the GX Device can transmit these tank levels on the NMEA 2000 network to be picked up by other displays such as an MFD.
Tank sender wiring is kept as simple as possible: 2 of the 4 inputs provide a 24V power supply, to power the sender. The other 2 channels will require an external power supply, and there is a power in terminal together with fused outputs to allow for that.
Upper and lower limits are configurable, to allow using senders that provide only part of the scale (for example 0 to 5V).
To provide a stable reading, the readings are averaged damping. The damping can be configured between 1 and 60 seconds.
Faulty sensors and wiring issues are detected: an alarm will be raised when values are out of range.
SKU: VCBPP920140100
