Meet our new portable. Even lighter. Even tougher.

The specification now includes two resting pads (side and rear), improved carry handles, battery-less EFI and full compatibility with our Digital Network Gauges.

With its single-lever steering friction adjustment, new wide-span motor mount, high-output alternator and options of Variable Trolling Speed, Y-COP Security and Wide Range Power Trim & Tilt, the 25hp is the natural choice.

At a glance

• 25% lighter – unique power-to-weight performance
• New tough and solid one-piece top cowling
• New battery-less EFI system for easy starting
• Manual, electric and manual/electric start options
• VTS slower-than-normal idle speed (option on r/c)
• Compatible with Yamaha Digital Network Gauges
• VTS (Variable Trolling Speed) option on r/c
• Wide Range Power Trim & Tilt option
• Exclusive Y-COP immobiliser security available
• Multi-function tiller handle option
• Single-lever steering friction (Tiller model)
• High-output alternator for extra starting power

Technical Information

Engine type

4-stroke

Displacement

432 cm?

No. of cylinders/configuration

2/In-line, SOHC

Bore x stroke

65.0 mm x 65.1 mm

Prop shaft output at mid range

18.4 / 6,000 rpm

Full throttle operating range

5,000 – 6,000 rpm

Lubrication system

Wet sump

Fuel Induction System

EFI

Ignition / advance system

CDI

Starter system

Electric/ Manual, Manual (MH), Electric (E, ET) with Prime Start?

Gear ratio

2.08 (27:13)

Recommended boat transom height

S424L:551mm

Fuel tank capacity

separate, 25litres

Oil pan capacity

1.1litres

Weight without propeller

56kg – 64kg
